This week we launched Supabase Storage, which leaves one other huge piece of the stack that everyone is asking for: Functions.
TLDR
We're not releasing Functions today. Trust us, we know you want them. They are coming, just not today.
But we are building something that we think you're going to like: Workflows. We haven't finished building it yet, but Workflows are a "piece" of the Function story and arguably an even more exciting feature.
Firebase Functions
Firebase functions are relatively simple. If you use Serverless, AWS Lambda, Cloudflare Workers, Next.js API routes, or Netlify Functions, then you know how they work. A Firebase function executes some code which you provide, without you managing a server.
Specifically for Firebase, they have another key feature - they can be triggered by database events. For example, you can trigger a function whenever a Firestore Document is updated.
This is great, but it is still limited for a few real-world use cases. For example, what if you want to send an email to a user one day after a user signs up. Or one year? There is no queuing functionality in Firebase. You'd have to manage a process like this yourself, probably using a cron-job.
A better solution?
We searched for some open source tools which we think are solving this problem well. We looked at NodeRed, n8n, Airflow, and about 10 other tools. They are amazing tools on their own, but for the Supabase Stack they ultimately had the same shortcomings that we found with Storage providers - most of them lacked deep Postgres integration.
We went back to the drawing board and asked, "if we could wave a wand and get the perfect solution, what would it look like?". The tool that came very close is AWS Step Functions. The only problem: it's not open source. Luckily, their state language is.
Using this states language, we are building an open source orchestration engine for managing very complex Workflows with queueing, etc. It will be built with Elixir.
This engine won't execute code. Instead, it will coordinate and execute existing functions wherever they live: AWS, GCP, Azure, OpenFaas, and of course Postgres.
We plan to add "modules" which work natively: email services, notification services, and other platforms.
The engine is deeply integrated with Postgres. Jobs
, queues
, and logs
will be stored and accessible by SQL. We'd like to give a shoutout to the Oban team here, their robust job processing was a big missing piece for the engine. And most importantly, it's backed by Postgres!
Once ready, we will make this available in the Supabase Dashboard with a Zapier-like interface.
What are Workflows
Workflows orchestrate and execute functions in response to a database event (insert, update, delete) or a HTTP call (direct invocation).
You can use them to rapidly develop microservices (once we have functions) without worrying about servers.
Workflows are stateless - the output of a state becomes the input of the next state.
Workflows are defined using Amazon States Languages, so you can import your workflows from AWS (although we are still building handlers for most AWS resources).
Workflows can be persistent (the default). This means they are tolerant to server restarts, but it also means they need to use the database to store their state.
Workers can be transient. These are fully in-memory if you don't want to store the execution state (for example, IoT applications that trigger workflows very often). Transient workflows are not restarted if the server crashes or is restarted.
Example
A typical use-case for workflows is sending emails. For example, you might want to send a user an email one day after they
sign up. In database terms we can say: "trigger an email workflow whenever there is an insert on the users
table."
Let's break this down into steps, then tie it all together at the end:
Sending an email
_10SendEmail:_10 Type: Task_10 Next: Complete_10 Resource: my-email-service_10 Parameters:_10 api_key: my-api-key_10 template_id: welcome-email_10 payload:_10 name.$: '$.record.name'_10 email.$: '$.record.email'
Here we have a "Task" which triggers a call to an email service (like Mailgun or Postmark). Specifically, it's telling
the service to send the welcome-email
template, and it's providing it a name
and an email
as parameters.
Waiting a day
Since we don't want to send the email immediately, we need to tell Workflows to wait one day
_10WaitOneDay:_10 Type: Wait_10 Next: SendEmail_10 Seconds: 86400
Here "one day" is specified in seconds.
Trigger on insert
We mentioned that you could trigger a workflow whenever there is an "insert" on the users
table. But what if you insert
multiple users at once? Not a problem - we can loop through all the inserts with a Map
:
_14EmailUsers:_14 Type: Map_14 End: true_14 InputPath: '$.changes'_14 Iterator:_14 StartAt: CheckInsert_14 States:_14 CheckInsert:_14 Type: Choice_14 Default: Complete_14 Choices:_14 - Variable: '$.type'_14 StringEquals: INSERT_14 Next: WaitOneDay
In this part, we have a task "EmailUsers", which iterates through all the database events ($.changes
) and checks if they are INSERTs.
Tying it all together
Let's see how it looks all together:
_34---_34Comment: Email users after one day_34StartAt: EmailUsers_34States:_34 EmailUsers:_34 Type: Map_34 End: true_34 InputPath: '$.changes'_34 Iterator:_34 StartAt: CheckInsert_34 States:_34 CheckInsert:_34 Type: Choice_34 Default: Complete_34 Choices:_34 - Variable: '$.type'_34 StringEquals: INSERT_34 Next: WaitOneDay_34 WaitOneDay:_34 Type: Wait_34 Next: SendEmail_34 Seconds: 86400_34 SendEmail:_34 Type: Task_34 Next: Complete_34 Resource: send-templated-email_34 Parameters:_34 api_key: my-api-key_34 template_id: welcome-email_34 payload:_34 name.$: '$.record.name'_34 email.$: '$.record.email'_34 Complete:_34 Type: Succeed
The workflow receives the following JSON data from Supabase Realtime:
_36{_36 "changes": [_36 {_36 "columns": [_36 {_36 "flags": ["key"],_36 "name": "id",_36 "type": "int8",_36 "type_modifier": 4294967295_36 },_36 {_36 "flags": [],_36 "name": "name",_36 "type": "text",_36 "type_modifier": 4294967295_36 },_36 {_36 "flags": [],_36 "name": "email",_36 "type": "text",_36 "type_modifier": 4294967295_36 }_36 ],_36 "commit_timestamp": "2021-03-17T14:00:26Z",_36 "record": {_36 "id": "101492",_36 "name": "Alfred",_36 "email": "alfred@example.org"_36 },_36 "schema": "public",_36 "table": "users",_36 "type": "INSERT"_36 }_36 ],_36 "commit_timestamp": "2021-03-17T14:00:26Z"_36}
Next Steps
We've already open sourced the Workflow interpreter here. It's built with Elixir, so you can find it on Hex here.
After we've ironed out a few bugs we will integrate it into the Supabase Stack. As with all Supabase features, we'll add a nice UI to make prototyping extremely rapid. We'll integrate the UI with the code (via Git) to make sure everything is version controlled.
